Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C A Card

The Simplecom EC315 is a versatile PCIe x4 expansion card designed to enhance your system's USB connectivity with four high-speed ports. This card supports both Type-C and Type-A interfaces, offering data transfer rates of up to 10Gbps via the USB 3.2 Gen 2 standard.

Display

N/A

Performance

• Pcie Interface: PCIe 3.0 x4 (compatible with PCIe x8 or x16 slots)
• Data Transfer Rate: Up to 10Gbps (USB 3.2 Gen 2)
• Backwards Compatibility: USB 2.0 and USB 1.1
• Power Source: Integrated PCIe 12V to 5V module, no external power required
• Overcurrent Protection: Built-in on each port

Connectivity

• Rear Panel Connectors: 1x USB-A, 1x USB-C
• Internal Connectors for Front Panel: 1x USB 3.0 (Front USB-A), 1x Key-A (Type-E) connector (Front USB-C)
• USB Speed Support: SuperSpeed+ (10Gbps), SuperSpeed (5Gbps), HiSpeed (480Mbps), Full Speed (12Mbps)

Compatibility

• Operating System: Windows 7 and above, automatic installation on Windows 8 and above, driver installation required for Windows 7
• System Requirement: Available PCIe 3.0 or higher x4/x8/x16 slot on motherboard

Package Contents

• 1x USB 3.2 Gen 2 Expansion Card
• 1x Low Profile Bracket
