Specifications
Specifications
Dimensions
| Length | 290 mm |
|---|---|
| Width | 226 mm |
| Height | 122 mm |
Product Details
Product Details
The DEEPCOOL PQ1000G WH is a fully modular ATX power supply with an output of 1000W and an efficiency rating of 80Plus Gold. It features Japanese electrolytic capacitors for reliability and includes DC to DC conversion technology.
Display
- No display panel (not applicable)
Performance
- Type: ATX12V V3.1
- Topology: Active PFC + Half Bridge SRC LLC + DC to DC
- Fan Size: 120×120×25mm (W x L x H)
- Fan Bearing: FDB (Fluid Dynamic Bearing)
- Hold Up Time: ≥16ms
- Full Load Efficiency: ≥90%
- Under Typical Load (50% Loading) Efficiency: Not specified in the data
- Mechanical Life: EAC MTBF 100,000 Hours
- Operating Temperature Range: 0-40°C
Protection
- OPP (Over Power Protection)
- OVP (Over Voltage Protection)
- SCP (Short Circuit Protection)
- OTP (Over Temperature Protection)
- OCP (Over Current Protection)
- UVP (Under Voltage Protection)
- SIP (Surge Immunity Protection)
- NLO (No Load Operation)
Regulatory and Certification
- EAC Erp Regulation: ErP 2013
- Efficiency certification: 80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Connectivity
No specific connectivity details provided (not applicable)
Warranty
Warranty
Manufacturer warranty 120 Months
