Corsair FRAME 4000D WOOD RS White E-ATX Mid-Tower PC Case 430MM GPU 170MM CPU

The Corsair FRAME 4000D WOOD RS is a modular mid-tower PC case that combines natural aesthetics with advanced cooling and build flexibility. It features a real wood front panel for a unique look and includes four pre-installed RS120 PWM fans for effective low-noise cooling.

Display

• Left side panel: Tempered glass
• Right side panel: Steel

Performance

• InfiniRail™ Fan Mounting System for easier building and fan installation
• Built-in GPU Anti-sag Stabilization Arm to secure long graphics cards
• Supports reverse-connector motherboards

Compatibility

• Motherboard form factors: Mini-ITX, Micro-ATX, ATX, E-ATX (up to 305mm x 277mm)
• CPU cooler height limit: 170mm
• Power supply length limit: 220mm
• Graphics card length support: Up to 430mm
• Radiator compatibility: 120mm, 140mm, 240mm, 280mm, 360mm
• Liquid cooler compatibility: H60, H100, H115, H150, NAUTILUS, TITAN

Connectivity

• Front IO: 1x USB 3.2 Gen 2x2 Type-C, 2x USB 3.2 Gen 1 Type-A, 1x Audio in/out
• Motherboard connections: 1x USB-3.2 Gen2x2 Type-E, 1x USB 3.2 Gen1 20-Pin, 1x F_PANEL, 1x HD Audio

Build Features

• Fully-modular design for customisation flexibility
• 7 expansion slots (horizontal or vertical)
• Includes dust filters and cable management space (37mm)
• RapidRoute included: No
• Vertical mount support: Supported (riser card sold separately)

Storage

• Internal 3.5" drive bays: 1
• Internal 2.5" drive bays: 2

Dimensions and Weight

• Height: 486mm
• Length: 490mm
• Width: 239mm
• Weight: 11.82kg

Warranty

2 Year Warranty
