Which 1TB NVMe SSD do you actually need?

Most PC builders get tripped up by the headline sequential speed on the box, when what you feel day to day is mostly random read latency, controller efficiency and how the drive behaves once its cache is full. At 1TB, the tiers differ in three real ways: NAND type, whether there's a dedicated DRAM cache, and the controller and interface.

Entry-level 1TB drives, like the Kingston NV series or Crucial P3, often use QLC NAND and are DRAM-less. They lean on Host Memory Buffer, which borrows a slice of system RAM for the mapping table. That's fine for boot, browsing and games, but once the fast pseudo-SLC cache fills during a big transfer, write speeds can fall to a fraction of the advertised figure.

The sweet spot is a PCIe 4.0 drive with TLC NAND, such as the Samsung 990 Pro or 990 EVO Plus, Crucial T500 or WD_BLACK SN850X. These hold sustained writes far better and have much stronger random performance at low queue depths, which is what Windows and game loading actually do. Enthusiast PCIe 5.0 drives like the Crucial T705 double the sequential bandwidth, but they run hotter and need serious heatsinks. Game load times barely change, because they're bottlenecked by CPU decompression and asset streaming rather than raw throughput. Diminishing returns hit hard above roughly 7,000 MB/s unless you're moving huge video or dataset files all day.

Upgrading and technical nuances

PCIe 5.0 support on current boards varies. On AM5 and LGA1851 Motherboards, usually only the primary M.2 slot is wired straight to the CPU at Gen5 speeds. The other slots often hang off the chipset at Gen4 or Gen3, with shared bandwidth through the chipset uplink. Check the manual before deciding which slot gets your fast drive.

Lane sharing is the classic trap. On many boards, populating a certain M.2 slot disables a pair of SATA ports, or drops your GPU slot from x16 to x8 if you've used the wrong combination. Modern Graphics Cards / GPU lose very little at x8 Gen5, but it's better to know than to find out later.

For capacity versus endurance, a 1TB TLC drive typically carries around 600TBW, which is more than most people will write in a decade. Better drives also hold their speed as they fill. Keep 10 to 20 per cent free on any SSD, since the controller uses that space for wear levelling and cache.

If you're building a PS5 expansion, you need a Gen4 drive with a heatsink that fits the slot's tight clearance. A WD_BLACK SN850X with the heatsink variant is a common pick. For a desktop, the fastest drive matters less than a good TLC drive with a proper cache. If you're also thinking about RAM, it's worth knowing that DRAM-less drives borrow a small amount of Desktop Memory, though it's trivial on any modern DDR5 setup.

Browse the full range of Solid State Drives (SSD) if you want to compare capacities and controllers side by side.

Practical things to check before buying

Start with form factor. Nearly all 1TB NVMe drives are M.2 2280, meaning 22mm wide and 80mm long, but some boards have shorter slots or tool-free latches that behave differently with heatsink-equipped drives. Double-sided drives and thick aftermarket heatsinks can foul on a Graphics Cards / GPU backplate, especially in the slot just under the primary PCIe lane. Measure the gap if you're running a chunky triple-slot card.

Thermals matter more than people admit. A Gen4 drive under sustained load can hit 70 to 80 degrees without airflow and will throttle. Most decent motherboards ship with a heatsink for at least the main slot, so don't double up with a second one unless you've removed the original. Gen5 drives need a proper heatsink and ideally airflow from a front intake, so look at the layout of your Computer Cases and whether you have fans over the M.2 area. If your case is airflow-limited, consider upgrading your Fans, Heatsinks & Cooling setup before spending extra on a hotter drive. A large air cooler from CPU Cooling can also shade the top M.2 slot, which affects how much cool air reaches it.

Power isn't a big concern. M.2 drives pull a few watts from the slot, so no extra cabling is needed. If you're building a whole system, spend your power budget on a quality unit from Power Supplies rather than worrying about the SSD.

Check that your CPU and board actually support the speed you're paying for. A Gen5 drive in a Gen4 slot works fine but runs at Gen4 speed. If you're building from scratch, check your CPUs & Processors choice supports Gen5 NVMe directly from the CPU lanes.

For pre-built options with fast storage already sorted, see Computers.

Brands and local warranty

The reliable names here are Samsung, Western Digital (WD_BLACK), Crucial, Kingston, Seagate (FireCuda), Corsair (MP series), Lexar and Sabrent. Samsung and WD tend to make their own controllers and NAND, which usually means more consistent performance. Crucial uses Micron NAND, and Kingston often sources third-party controllers but has a strong support record.

Genuine Australian warranty matters. Under Australian Consumer Law you have guarantees that sit on top of the manufacturer's warranty, and a local reseller means a proper RMA path instead of shipping a drive overseas. Grey imports might save a few dollars, but warranty claims can turn into a mess. Most reputable 1TB NVMe drives carry a three to five year warranty tied to a TBW limit, so keep your invoice. Also back up before any RMA, because replacement means your data is gone.

Frequently asked questions

Is 1TB enough for gaming today?

For one main library, yes, but it fills faster than you'd expect. Many modern AAA titles sit between 100GB and 200GB, so a handful of installs plus Windows will eat a lot. If you play lots of big games, 2TB is more comfortable, though 1TB works well if you rotate titles.

Do I need a PCIe 5.0 NVMe SSD?

Probably not. For gaming and general use, a good Gen4 TLC drive feels identical in practice. Gen5 only makes sense if you regularly move huge files, and you must be able to cool it properly.

Will a DRAM-less drive be a problem?

Not for typical use. Quality DRAM-less TLC drives like the Samsung 990 EVO Plus are perfectly good for gaming and everyday work. The weak spots are heavy sustained writes and cheap QLC models once the cache is full.

Can I use any NVMe SSD in my PC?

Mostly, if you have a free M.2 slot that supports NVMe, which nearly all current boards do. Check for SATA-only M.2 slots on older or budget boards, and make sure the length fits.

Do I need a heatsink?

If your motherboard provides one, use it. Gen4 drives generally run fine with a basic heatsink and airflow, while Gen5 drives really need a good one. Bare drives in a hot, closed case can throttle under load.
