TP-Link CPE210 2.4GHz 300Mbps 9dBi Outdoor CPE AP 5km Range

The TP-Link CPE210 is a high-performance outdoor client premises equipment (CPE) access point designed for long-range wireless transmission up to 5km. It features built-in 9dBi 2x2 dual-polarized directional MIMO antenna and supports adjustable transmission power from 0 to 27dBm/500mw.

Performance

• Processor: Qualcomm Atheros 560MHz CPU, MIPS 74Kc
• Memory: 64MB DDR2 RAM, 8MB Flash
• Wireless Speeds: Up to 300Mbps (40MHz, Dynamic), up to 144.4Mbps (20MHz, Dynamic), up to 72.2Mbps (10MHz, Dynamic), up to 36.1Mbps (5MHz, Dynamic)
• TP-LINK Pharos MAXtream TDMA technology for improved performance in throughput, capacity and latency

Connectivity

• 2x Shielded Ethernet Ports: 1 LAN0 (Passive PoE in), 1 LAN1 (Passive PoE Passthrough)
• Supports Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) up to 60 meters
• Dimensions: 224 x 79 x 60 mm

Protection and Certification

• 15KV ESD Protection, 6KV Lightning Protection
• Outdoor ASA stabilized plastic material enclosure
• IPX5 waterproof certification

Wireless Standards

• IEEE 802.11b/g/n (with Pharos MAXtream disabled)
• TDMA Mode (with Pharos MAXtream enabled)
• Frequency: 2.4~2.483GHz

Operation Modes

• AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP)
