Gigabyte B850M FORCE WIFI6E AMD AM5 2 x DDR5 1 HDMI 2 PCI-E x16 3 M.2

The Gigabyte B850M FORCE WIFI6E is a high-performance motherboard designed for AMD AM5 sockets and supports up to two DDR5 memory slots with a maximum capacity of 128 GB (64 GB single DIMM). It features:

Display

• 1 x HDMI port, supporting resolutions up to 4096x2160@60 Hz and HDCP 2.3 with HDR support.
• 1 x DisplayPort, supporting resolutions up to 3840x2160@144 Hz.

Performance

• Support for AMD Ryzen™ 9000/7000 Series Processors with PCIe 5.0 x16 mode and AMD Ryzen™ 8000 Series-Phoenix processors with PCIe 4.0 modes.
• Integrated Realtek® 2.5GbE LAN chip supporting speeds up to 2.5 Gbps/1 Gbps/100 Mbps.

Storage

• 3 x M.2 slots: 1 integrated in the CPU and supports PCIe 4.0, while the other two are on the chipset supporting PCIe 4.0.
• RAID support for NVMe SSDs (RAID 5 available only with AMD Ryzen™ 9000 Series Processors).
• 4 x SATA 6Gb/s connectors for RAID configurations of 0, 1, and 10.

Connectivity

• 2 x PCI Express x16 slots supporting PCIe 5.0/x4 modes.
• USB ports: 1 USB Type-C® with USB 3.2 Gen 1 support, 1 x USB 3.2 Gen 2 Type-A port (red), and multiple USB 2.0/1.1 ports on the back panel and through internal headers.

For detailed compatibility information regarding CPUs and memory configurations, please refer to Gigabyte's website.
