Gigabyte UD750GM ICE PG5 750W ATX Gold PSU Black Flat Cables

The Gigabyte UD750GM ICE PG5 is a high-performance power supply unit (PSU) designed for modern PC builds. It features an 80 PLUS Gold efficiency rating and supports Intel's ATX 3.0 standard along with PCIe Gen 5.0 graphics cards.

Display

N/A

Performance

• PFC: Active PFC (>0.9 typical)
• Efficiency: 80 PLUS Gold certified with efficiency >90% at typical load
• Fan Type: 120mm Hydraulic Bearing (HYB) fan
• Mechanical Life: MTBF >100,000 hours
• Hold Up Time: >16ms
• Protection Features: OVP/OPP/SCP/UVP/OCP/OTP

Connectivity

• Cable Type: Flat, all black cables
• Connectors:
  • ATX/MB 20+4 Pin x 1 (610mm)
  • CPU/EPS 4+4 Pin x 2 (600mm + 200mm)
  • PCIe 16 Pin x 1 (700mm)
  • PCIe 6+2 Pin x 4 (600mm + 150mm each)
  • SATA x 8 (600mm + 150mm each)
  • 4-Pin Peripheral x 3 + 4-Pin Floppy x 1 (500mm + 120mm each)

Specifications

• Model: GP-UD750GM PG5
• Input Voltage: 100-240 Vac (full range)
• Input Current: 12-6A
• Input Frequency: 60-50 Hz
• Output Capacity: 750W
• Dimension: 150 x 140 x 86mm
